Frameset
Frame: IMPULSO RC Disc Brake, Flat Mount 140/160, PressFit 86.5x41 bottom bracket, thru axle 12x142 mm, SRAM UDH hanger, carbon frame
Fork: Bianchi Impulso integrated fork, Flat Mount 140/160, thru axle 12x100, tire clearance up to 42 mm, carbon construction
Headset: Bianchi Custom Acros ICR, internal cable routing system, angular contact bearings
Drivetrain
Shifters: SRAM RED AXS HRD
Rear Derailleur: SRAM RED XPLR AXS
Crankset: SRAM RED XPLR power meter, crank length 170–175 mm depending on size
Bottom Bracket: SRAM DUB PressFit Road Wide 86.5x41
Chain: SRAM RED Flattop with PowerLock D1
Cassette: SRAM RED XPLR XG-1391, 10-46T, XDR driver
Brakes
Brakes: SRAM RED hydraulic disc brake, steel-backed organic pads
Rotors: SRAM Paceline X, Centerlock, 160 mm front and rear
Wheels
Wheels: Reparto Corse 43G Ceramitech
Tires: Pirelli Cinturato Gravel RC 700x40c, 60 TPI, tubeless ready, tan sidewall
Cockpit
Handlebar: Reparto Corse AeroFlare carbon handlebar, 16° flare, reach 80 mm, drop 120 mm
Grips: Bianchi Arrow tape 2.5 mm black
Saddle
Seatpost: Bianchi Custom D-Shape carbon, 20 mm offset, 300–380 mm depending on size
Saddle: Bianchi RC139 carbon, 145 g, 139 mm width, carbon rails
Based on component availability, Bianchi reserves the right to make changes on specifications without notice.
